SpaceX COTS demo 2 flight updates

– May 18, 2012

SpaceX is attempting to make history this weekend by sending their Dragon capsule to dock with the International Space Station. I will be providing periodic updates here, and on my Twitter account.

***

May 19, 6:45PM EDT: SpaceX has traced the issue in engine number five to a faulty turbopump valve. Replacement of the valve is expected to be completed this evening, according to a statement obtained by SpaceflightNow.com. SpaceX’s official Twitter account reported that the next launch attempt will be Tuesday, May 22 at 3:44AM EDT.

May 19, 2:00PM EDT: I posted an update article on the Planetary Society blog:

The launch of SpaceX’s Falcon 9 rocket and Dragon capsule was aborted last night a half-second before liftoff, due to abnormally high pressure readings in engine number five. SpaceX technicians will head to the launch pad today to visually inspect the engine today before deciding on a course of action.

Here’s a video of the launch abort:


Depending on the severity of the issue, options range from adjusting the acceptable launch pressure constraints to all-out replacement of the engine. SpaceX has a spare engine onsite at Cape Canaveral, but installing it would likely cause further delays. The next available launch window is Tuesday, May 22 at 3:44AM EDT (7:22 UTC), and another opportunity occurs on May 23. Launch windows for the COTS 2 demonstration flight are very narrow due to the amount of propellant the Dragon spacecraft requires to perform its demonstration maneuvers when it reaches the International Space Station.

Aborting the launch of a liquid-fueled rocket moments before liftoff is dramatic, but a routine procedure when sensors on the vehicle detect an issue. The space shuttle, in fact, went through similar launch aborts a handful of times throughout the program. Here’s a video montage of a few; notice how the shuttle stack continues to sway after the main engines cutoff, creating an unnerving situation for the astronauts inside the vehicle.

The astronauts on the International Space Station will continue to wait for the Dragon spacecraft’s arrival. The orbiting laboratory passed directly over Cape Canaveral just minutes before last night’s launch attempt, providing a photo opportunity for ESA astronaut André Kuipers.

cape-canaveral-from-ISS

A picture of Cape Canaveral from the International Space Station as it passed overhead, just a few minutes prior to May 19's aborted Falcon 9 launch attempt. Credit: André Kuipers

May 19, 4:04AM EDT: The main engines ignited, but shut down due to high chamber pressure in the fifth engine. The Falcon 9 has nine engines, all of which must be within optimal parameters for the rocket to commit to launch. SpaceX will only launch when the orbit of the ISS is optimal to save propellant for the Dragon’s demonstration maneuvers. The next attempt will be Tuesday morning at 3:44AM EDT.

May 19, 3:45AM EDT: Ten minutes and counting. SpaceX has completed their launch readiness poll and all stations report GO.

May 19, 4:30AM EDT: The Falcon 9 is fueled with LOX and RP-1, and is currently in a replenishment mode. Weather for the launch, 25 minutes from now, remains 80% favorable. SpaceX is not working any issues. The USAF reports a GO for the range.

falcon9

The Falcon 9, fueled and ready for launch. Credit: NASA TV

May 18, 10:15PM EDT: By now, both vehicles should be powered on. Liquid oxygen loading should start in just under three hours, at 1:05AM EDT. Rocket-grade kerosene loading will begin ten minutes later.

An earlier Tweet from Elon Musk said, “Next time Dragon sees the sun, it should be doing 17,000 mph over the Atlantic. ~8 hrs to liftoff.”

elon-musk-falcon-tweet

The Falcon 9 stands ready to launch. Credit: SpaceX / Elon Musk

May 18, 4:30PM EDT: SpaceflightNow has pictures of the Falcon 9 on its launch pad.

May 18, 3:15PM EDT: SpaceX’s Falcon 9 rocket was moved to the launch pad overnight. Weather remains 70% favorable for tomorrow morning’s 4:55AM EDT launch. Pre-launch activities will commence around 9:25PM EDT, when the rocket and capsule are powered on to prepare for launch.

falcon9

The Falcon 9 rocket after it was moved to the pad last night. Credit: NASA

0

Planetary Society: SpaceX set to launch COTS 2 flight this Saturday

– May 18, 2012

This Saturday, SpaceX will attempt to make history by launching the first commercial spacecraft to berth with the International Space Station. The flight will demonstrate the Dragon spacecraft’s readiness to begin official cargo runs to the orbiting laboratory. NASA has signed off on twelve resupply flights, which could begin later this year. But before that happens, SpaceX has to prove their vehicle is up for the challenge.

spacex-cots2-demo-patch

The official mission patch for Commercial Orbital Transportation Services Demo 2, SpaceX’s inaugural flight to the International Space Station. Credit: SpaceX



It has been six years since NASA began accepting proposals for their Commercial Orbital Transportation Services (COTS) program. A press release at the time challenged private industry to “open new space markets and support the crew and cargo transportation needs of the International Space Station.” SpaceX’s May 19 flight, scheduled for a 4:55AM EDT (8:55 UTC) liftoff, marks the culmination of NASA’s efforts to pass the banner of low-Earth orbit cargo services from the space shuttle program to the commercial spaceflight industry.

The Falcon 9 rocket and Dragon capsule have not flown since their first demonstration flight in December 2010, during which the Dragon became the first privately-built spacecraft to orbit the Earth and return to the ground intact for recovery. To date, only the governments of the United States, Russia and China have accomplished this feat.

Private spaceflight has been at the heart of differing opinions regarding U.S. space policy. SpaceX has become the most visible symbol of the burgeoning industry, and the outcome of this flight will likely be used as a talking point for stakeholders on all sides of the debate. But despite the clenched-teeth excitement surrounding the launch, the flight remains a demonstration of the Dragon’s ability, not an official cargo run. 520 kilograms of food and supplies are going up, and 660 will come down, none of which are mission-critical should the flight end in disaster.

Commercial Orbital Transportation Services Demo 2, or COTS 2, combines a list of SpaceX objectives that were originally slated to take place during two separate flights, with berthing not scheduled until the second (COTS 3). However, last year, SpaceX approached NASA about the possibility of combining the missions, and the space agency agreed.

Before proceeding, SpaceX had to overcome ongoing issues with the Dragon capsule’s software testing and validation. NASA and its International Space Station partners have to be assured that the Dragon will respond properly in the event flight controllers order it to stop its approach. Additionally, SpaceX alluded to their own concerns that the Dragon might call for an abort when one was not necessary.

Launch activities get started the previous evening on May 18, as the Falcon 9 is prepared for flight. The launch window of 4:55AM EDT (8:55 UTC) is an instantaneous launch window, meaning any delay in the count forces a scrub, with the next launch window occuring three days later. Why such narrow constraints? The Dragon will be consuming a lot of propellant as it performs its space station flyaround and demonstration maneuvers. SpaceX wants to launch only at times that will minimize the amount of fuel required to catch up with the International Space Station, which completes an orbit around the Earth every 90 minutes.

Your correspondent plans on waking up around 4:30AM EDT on May 19 to watch and live Tweet the historic event. I also plan on posting live updates to my blog throughout the weekend as the mission progresses.

Here is the current mission timeline. This information comes from SpaceX’s press kit, and is subject to change.

FLIGHT DAY 1
Prelaunch events

Time to liftoff, H:M:S Event
7:30:30 Vehicles are powered on
3:50:00 Commence loading liquid oxygen (LOX)
3:40:00 Commence loading RP-1 (rocket-grade kerosene)
3:15:00 LOX and RP-1 loading complete
0:10:30 Falcon 9 terminal count autosequence starts
0:05:30 Dragon terminal count auto starts
0:02:30 SpaceX Launch Director verifies go for launch
0:02:00 Range Control Officer (USAF) verifies range is go for launch
0:01:00 Command flight computer state to startup, turn on pad deck and Niagara Water
0:00:40 Pressurize propellant tanks
0:00:03 Engine controller commands engine ignition sequence to start
0:00:00 Falcon 9 Launch



Ascent events

Time after liftoff, H:M:S Event
0:01:24 Max Q
0:03:00 1st stage engine shutdown/Main Engine Cut Off (MECO)
0:03:05 1st and 2nd stages separate
0:03:12 Stage 2 engine starts
0:03:52 Dragon nose cone jettisoned
0:09:14 2nd stage engine cut off (SECO)
0:09:49 Dragon separates from 2nd stage



On orbit operations/initial demonstrations in the far field

Time after liftoff, H:M:S Event
0:11:53 Start sequence to deploy solar arrays
0:54:49 Demonstrate absolute GPS
2:26:48 Start GNC Bay door deployment (holds sensors necessary for rendezvous)
2:40:49 Relative navigation sensors checkout, checks LIDAR and Thermal Imager
8:46:52 Demonstrate full abort, demonstrates Dragon’s ability to abort with a continuous burn
9:57:58 Pulsed abort demonstration, checks Dragon’s ability to perform abort using pulsating burns
10:37:58 Demonstrate Dragon’s ability to free drift



FLIGHT DAY 2
Phasing, Dragon moves closer to the ISS

  • Co-elliptic burns, place Dragon in a circular orbit
  • Height adjust burns, start adjusting altitude higher towards station

FLIGHT DAY 3
Flyby

  • Height adjust burn carries Dragon 2.5 km below the station (GO/NO-GO)
  • Dragon demonstrates relative GPS
  • Dragon starts receiving and transmitting information from/to the CUCU unit on the station
  • Height adjust burn carries Dragon away from ISS

FLIGHT DAY 3/4
Re-rendezvous

  • Dragon begins burns that carry the spacecraft above the space station (GO/NO-GO)
  • Rear height adjust burn, Dragon starts a series of maneuvers that place it behind and below the space station (GO/NO-GO)

FLIGHT DAY 4
Height adjustment maneuvers

  • Height adjust burn, Dragon begins burns that bring it within 2.5 km of station (GO/NO-GO)
  • Dragon again receives and sends information from/to the CUCU unit on station
  • Height adjust burn, brings Dragon 1.2 km from station (GO/NO-GO)
  • Height adjust burn, carries Dragon into the station’s approach ellipsoid (GO/NO-GO)

R-bar to capture (Radial bar is an imaginary line connecting ISS to the center of the Earth)

  • Dragon LIDAR Demo, shows LIDAR is providing Dragon with necessary information for proximity operations
  • Dragon holds at 250 meters (GO/NO-GO) for Demo Maneuvers
  • Dragon begins R-Bar Demonstration (GO/NO-GO)
  • Dragon holds at 30 meters
  • Dragon holds at capture point, 10 meters below the station
  • Station’s robotic arm (SSRMS) captures Dragon (GO/NO-GO)
  • Dragon berths

RETURN (TBD)

  • Dragon vestibule de-mate and depressurization
  • Station’s robotic arm uninstalls Dragon
  • Robotic arm releases Dragon
  • Dragon starts departure burns
  • Dragon closes the guidance, navigation and control bay door
  • Deorbit burn
  • Trunk jettisoned
  • Drogue chutes deployed
  • Main chutes deployed
  • Dragon lands in water and is recovered
